Range of Adjustment |
Basic Height: 28.3" - 46.9" (719 mm – 1,191 mm) Extended Height: 22.6" - 48.7" (574 mm – 1,237 mm) |
Glide Adjustment |
½" (14 mm) Desk 1" (25 mm) Bench |
Distributed Weight Capacity Tip: When calculating lifting capacity, subtract the weight of the worksurface. |
2- leg (desk and bench): 250 lbs. (113 kg) |
Wire Management Included |
Yes |
Controller |
Up-Down, Digital Preset |
Decibel Rating |
< 55 dBA |
Volts |
2- leg: 100V – 127V AC, 220-240V AC |
Frequency & Phase |
60 Hz, Single-Phase |
Amps |
2- leg: 5A max for 100V – 127V AC, 2A max for 220-240V AC |
Watts |
2- leg: 540W |
Standby Power |
2- leg: 0.03W |
Adjustability Speed |
1.3"/sec. (33 mm/sec) |
Duty Cycle |
10% (2 min. on, 18 min. off) |
Weight of Worksurface: ~4.03 lb/ft2 (19.97 kg/m2), or ~0.028 lbs/in2 (0.019 g/mm2)
Rectangular tops weigh between 38 – 70 lbs (17 – 32 kg); a 58"x29" top weighs 48 lbs.
